1.What Is a Switchgear Retrofit—and When Does Your Facility Need One?
Switchgear Retrofit

What Is a Switchgear Retrofit—And When Does Your Facility in Wenzhou Need One?

Switchgear retrofitting is a cost-effective way to modernize outdated electrical systems without tearing out and replacing entire switchgear lineups. Instead of full replacement, this method reuses the structural components—such as the cabinet, busbars, and enclosure—while upgrading the internal components like circuit breakers, relays, protection devices, and meters.

Switchgear Retrofit This drastically reduces both downtime and capital expenditure, especially for critical infrastructure like industrial plants or refineries, where shutdowns can cost millions per day.

Switchgear Retrofit
Switchgear Retrofit

Switchgear Retrofit Common Scenarios That Call for a Retrofit:

  • OEM parts are obsolete or too expensive
  • Facility needs to upgrade capacity, safety, or protection systems
  • Full system shutdown for replacement is not feasible
  • Compliance with updated standards (IEEE, OSHA, NFPA 70E) is required to avoid liability or insurance issues

According to IEEE C37.59-2018, a retrofit is not merely a repair—it is legally considered a new design. This means it must be tested and documented to verify compliance with design and safety standards. This includes verifying:

  • Mechanical interfaces (e.g., racking systems)
  • Electrical performance ratings
  • Insulation systems
  • Interlocks and operational safety

Factory production testing alone is not sufficient.


Switchgear Retrofit Risks of Improper or Uncertified Retrofits:

  • Loss of UL or NRTL certifications, making the equipment non-compliant
  • Increased arc flash risk if interlocks or clearances are improperly modified
  • Insurance invalidation due to unauthorized modifications
  • Equipment failure or operational outages due to incompatibility with modern components

Many facilities unknowingly void their UL listing or NRTL compliance by using general contractors or unauthorized repair shops. Once a key component like a breaker or trip unit is replaced, the entire assembly is classified as a new product—and must be re-certified.


Why Gongshun Electric Is the Right Partner in Wenzhou

As a UL/NRTL-affiliated certified manufacturer, Gongshun Electric offers:

  • Verified retrofits that maintain or exceed original ratings
  • Full documentation for OSHA and NFPA 70E compliance
  • Custom adapters to fit new components into legacy enclosures
  • Faster lead times and minimal downtime through local Wenzhou-based service

Frequently Asked Questions

Can I upgrade switchgear without replacing the entire unit?

Yes. Retrofitting allows you to keep the existing cabinet and busbar structure while upgrading internal components like breakers, relays, and meters. This reduces both costs and downtime—when done by a qualified, certified manufacturer.

What is the average service life of medium voltage switchgear?

Typically 25–40 years, depending on environment, loading cycles, and maintenance. Retrofitting can extend that lifespan significantly.

Is switchgear retrofitting safe and code-compliant?

Only if performed by a certified manufacturer and verified under IEEE C37.59-2018 with proper documentation from UL or an NRTL. Gongshun Electric ensures full compliance.

How does retrofitting differ from full replacement?

Retrofitting updates the internal working components, while full replacement removes and replaces everything. Retrofitting is faster, cheaper, and less disruptive.

Who can certify a retrofit in Wenzhou?

Only a UL-verified manufacturer or one working under a Nationally Recognized Testing Laboratory (NRTL) such as UL or Intertek. Engineers, contractors, and test technicians—while skilled—are not authorized to certify retrofits under IEEE C37.59-2018.

Gongshun Electric coordinates directly with NRTLs and conducts internal testing to verify all performance, dielectric strength, interlocks, and fault-handling capabilities.


Arc Flash Safety After Retrofit—Don’t Assume, Verify

Arc-resistant switchgear is engineered to safely redirect energy from an internal arc event. But if the gear is modified—by replacing breakers, adding viewing windows, or altering insulation—its arc-resistant rating is no longer valid unless it is re-tested.

According to IEEE C37.20.7 and C37.59, arc resistance can only be claimed if:

  • Post-retrofit gear is subjected to full arc-fault type testing
  • Testing is conducted under lab conditions on the actual modified configuration

Field contractors or electricians may falsely assume arc resistance still applies after a retrofit—but without testing and documentation, this creates serious safety, legal, and insurance risks.

Gongshun Electric eliminates that risk by offering:

  • Verified arc-resistant upgrades
  • Custom enclosure designs with exhaust ducting
  • Coordination with UL, Intertek, or other NRTLs
  • Documentation for compliance with NFPA 70E, OSHA 1910, and NEC 110.16

Final Thought:

If your Wenzhou facility is considering a switchgear retrofit, don’t compromise on compliance or safety. Work with Gongshun Electric—a certified manufacturer with the engineering, testing, and documentation capability to deliver code-compliant, fully certified retrofits that protect both your operations and your people.
